Product FAQs

What is the difference between the Hercules 3000 and Hercules 6000?

1. The Hercules 6000 System is 20% faster than the Hercules 3000 System. The main difference is that the main water pump in the Hercules 6000 System is a 5HP pump oppose to the Hercules 3000 System that has a 3HP main water pump.
2. The second difference is that the Hercules 6000 System has an overhead spray bar that moves back and forth over the top of the vehicle while the frame moves up and down around the vehicle, this allows the vehicle to rinse off faster. Therefore, one operator with the Hercules 6000 System can comfortably wash, wax and seal 50 to 60 vehicles a day, 2 operators can handle over 120 vehicles a day. With the Hercules 3000 System one operator can wash, wax and seal 40 to 50 vehicles a day, 2 operators can do over 100 vehicles a day.

What size is the Hercules 3000, Hercules 6000 & Hurricane?

Hercules 3000

• Sizes: 9’ × 22’ for small- to medium-size vehicles and 11’ × 25’ for larger vehicles. Custom builds are available to accommodate oversized vehicles, as well as any wash bay size or layout.
  • Hercules 3000 Bay Layout
  • 9’ × 22’ Hercules 3000 Bay Layout Blueprint
  • 11’ × 25’ Hercules 3000 Bay Layout Blueprint
  • Customized Layout Portfolio

Hercules 6000

• Sizes: 9’ × 22’ for small- to medium-size vehicles and 11’ × 25’ for larger vehicles. Custom builds are available to accommodate oversized vehicles, as well as any wash bay size or layout.
  • Hercules 6000 Bay Layout
  • 9’ × 22’ Hercules 6000 Bay Layout Blueprint
  • 11’ × 25’ Hercules 6000 Bay Layout Blueprint
  • Customized Layout Portfolio

Hercules Hurricane

• Sizes: 9’ × 22’ for small- to medium-size vehicles and 11’ × 25’ for larger vehicles. Custom builds are available to accommodate oversized vehicles, as well as any wash bay size or layout.
  • Hercules Hurricane Bay Layout
  • 9′ x 22′ Hercules Hurricane Bay Layout Blueprint
  • 11′ x 25′ Hercules Hurricane Bay Layout Blueprint
  • Customized Layout Portfolio

System Requirements

Below is a list of the service requirements  for the Hercules Vehicle Wash, Wax and Sealant Systems

1. ELECTRICAL 1-220 VAC; 30 AMP; 60Hz; Single Phase 1-110 VAC; 30 AMP; 60Hz; Single Phase
2. WATER 3/4″ to 1″ NPT @approx 40 PSI
3. AIR 9.0 CFM @ 120 PSI
4. DRAIN 2 inch minimum

Custom Built Wash Bays
